  • Summary
  • Applications

    Machinery engineering industry has become the leading industry in China after a long and stable development. The grabbing machines，bucketing machines，cranes，building machines，agriculture machinery are widely used in civil building，railway， high way，port，farmland，electric and mining industries.


    To make these machines，you need Neway CNC machinery.

    Major related productsMore>
    Typical Machining Parts
    Gearbox cover
    Chain union
    Weight support wheel
    Cylinder
    Auto parts
  • Weight Support Pulley


    • QQ截图20181127095736.png

      Characteristics：
      Supporting pulleys bear the weight of the digger or bulldozer and guide the direction of the tracks, made of ASTM1045 or 080A40, cast or forged, heat treated and quenched, hardness around HRC38 to increase wearness resistance
    • QQ截图20181127095745.png

      Model recommended：
      NL503H CNC lathe
      Requirement：
      1.strict coaxiality, self-centered collect chuck
      2.powerful cutting, rigid machine bef and carriage
      3.supporting pulley material ASTM1045 or 080A40, high hardness, need to euip rigid spindle
      4.deep boring, rigit boring tool shank
      5.no need to equip tailstock tool shank
      • QQ截图20181127095800.png
      Process
      OP10 three jaw chuck holds part by right end face and bore
      OP20 collect chuck holds part by right end face and bore
  • Chain Union



    • QQ截图20181127095510.png

      Characteristics：
      35MnB forging workblank, difficult to fix, rigid fixture, requires powerful cutting force for D32 hole
    • QQ截图20181127095522.png

      Model recommended：
      VM1103H Vertical milling center
      requirement：
      1.MRNC255 face plate
      2.DAT255 strong tailstock
      • QQ截图20181127095543.png
      Process
      1. Positioning by the side of the part, 1 mount 2 parts, the 4th axis porcesses pinholes and side thread hole, 1/1000 rotary table could produce holes of any degree. Placing a supporting cylinder under the part make it possible to produce powerful heavy duty force. The expander between the two parts ensures best re-positioning accuracy and the parts steady by positioning surface.
      2.Supporting cylinder produces a supporting force of 500kg for parts of 2-3kg weight
      3.Expander is suitable for tightening parts with narrow space in between.
  • Cylinder



    • QQ截图20181127095625.png

      Characteristics：
      TAluminium cylinder, thin wall, collect chuck, i.d. 400mm, cylindricity 0.018，deep boring with reinforced boring seat and shock sbsorbing cutter shank
    • QQ截图20181127095635.png

      Model recommend：
      NL324H CNC Lathe
      Basic requirement：
      NL324H is a 2 coordinate, semi-ring and 2 synchronized axes CNC lathe. It is of integral design for mechanic, electronic and hydraulic system. Full enclosure, leftward slider door, swing type control panel on right side and fixed on the machine
      cover,ergonomic and easy for operation
      • QQ截图20181127095641.png
      Process
      make bore, internal thread and 22 degree bevel with one mount
  • Gearbox cover



    • QQ截图20181127095828.png

      Characteristics：
      gear box material ductile iron. process after the two parts coupled to ensure the  bearings co-axial to be 0.02.
    • QQ截图20181127095841.png

      Model Recommend：
      NL504SA turning lathe
      Equipment：
      NL504SA is a lathe with integrated machine bed, rectangular plastic sliding guideway, good dynamic performance, rigidity, chip removal, easy operation and pleasant experience, a good machine with competitive price, widely used in all industries.
      • QQ截图20181127095814.png
      Process
      OP10 positioning by two centers, collect chuck, turning o.d. and end face on both ends with one mount
      OP20 counter turning tool processes o.d.
